Total length of equipment | 35000mm | Width | 3000mm | Height | 2800mm |
Material width | 1000mm-1200mm or customized | Effective width | 980mm |
Power | Motor power:32KW; | Working voltage | 3P380V50HZ |
Productivity | 0-4m/min |
Weight | About 12T-14T |
Under frame | Steel Construction |
Tile press | Forming 13 rows of shafts. Shaft: φ 70. Middle plate: 12mm. Frame: 250h steel. Chain wheel and chain: 6 points |
Spacer sleeve | Using galvanized pipes for precision processing and electrostatic spraying |
Roller material | Ordinary |
Control system | PLC brand:Delta ; Frequency brand:Delta ; Operation brand:Delta |
Component | Discharge rack, tile press, composite main engine, cutting part, drag rack |
Thickness of sheet | 0.3-0.8mm |
Warranty period | 12 months, lifelong maintenance |
