| Total length of equipment | 35000mm | Width | 3000mm | Height | 2800mm |
| Material width | 1000mm-1200mm or customized | Effective width | 980mm |
| Power | Motor power：32KW； | Working voltage | 3P380V50HZ |
| Productivity | 0-4m/min |
| Weight | About 12T-14T |
| Under frame | Steel Construction |
| Tile press | Forming 13 rows of shafts. Shaft: φ 70. Middle plate: 12mm. Frame: 250h steel. Chain wheel and chain: 6 points |
| Spacer sleeve | Using galvanized pipes for precision processing and electrostatic spraying |
| Roller material | Ordinary |
| Control system | PLC brand：Delta ； Frequency brand：Delta ； Operation brand：Delta |
| Component | Discharge rack, tile press, composite main engine, cutting part, drag rack |
| Thickness of sheet | 0.3-0.8mm |
| Warranty period | 12 months, lifelong maintenance |
