| Total length of equipment | 1500mm | Width | 2000mm | Height | 1300mm |
| Material width | 1200mm or customized | Effective width | 750mm | ||
| Power | Motor power：11KW；Hydraulic power：5.5KW | Working voltage | 3P380V50HZ | ||
| Productivity | 12m/min | ||||
| Weight | About 1.5T | ||||
| Transmission type | Chain | ||||
| Under frame | 350H steel | ||||
| Shaft | 20rows layer,Diameter 90mm | ||||
| Connecting plate | 14mm | ||||
| Spacer sleeve | Using galvanized pipes for precision processing and electrostatic spraying | ||||
| Roller material | Ordinary | ||||
| Control system | PLC brand：Delta ； Frequency brand：Delta ； Operation brand：Delta | ||||
| Cutting type | Slipway shear | ||||
| Thickness of sheet | 0.3-0.8mm | ||||
| Warranty period | 12 months, lifelong maintenance | ||||
