Total length of equipment | 57000mm | Width | 800mm | Height | 1250mm |
Material width | 400mm or customized | Effective width | 300mm |
Power | Motor power:4KW;Hydraulic power:4KW | Working voltage | 3P380V50HZ |
Productivity | 12m/min |
Weight | About 5T |
Transmission type | Chain |
Under frame | 350H section steel |
Shaft | 10rows layer,Diameter 70mm |
Connecting plate | 14mm |
Spacer sleeve | Using galvanized pipes for precision processing and electrostatic spraying |
Roller material | Ordinary |
Control system | PLC brand:Delta ; Frequency brand:Delta ; Operation brand:Delta |
Cutting type | Cut with three knives |
Thickness of sheet | 0.3-0.8mm |
Warranty period | 12 months, lifelong maintenance |
